    2pr 30awg Double Shielded Audio Cable

    Ask Lasest Price
    Brand Name : dingzun
    Model Number : y-105
    Certification : ul
    Price : 1M/0.45~4USD
    Payment Terms : L/C, T/T
    Supply Ability : 1000M/1DAYS
    Delivery Time : 15DAYS
    • Product Details
    • Company Profile

    2pr 30awg Double Shielded Audio Cable

    Conductor: silver copper
    Construction: 30AWG
    PAIRS:2
    PAIR TWISTED: REQUIRED
    Insulation FEP
    IS: AL PET+ DRAIN WIRE
    OS: galvanized steel braided
    Jacket:FEP
    Rated temp:-60℃-180℃
    Type:multi pair audio cable

    Thank you for providing the details about the 2pr*30awg double shielded audio cable.

    This cable is specifically designed for use in audio applications where signal quality and noise immunity are critical. The cable has two pairs of conductors, each made of silver copper with a 30AWG construction, providing excellent conductivity and stability in signal transmission. The conductors are twisted to reduce crosstalk and improve signal quality.

    The insulation material used is FEP, which is known for its high temperature resistance, excellent dielectric properties, and low signal attenuation. The cable has an IS (inner shield) made of AL PET+ drain wire, which provides excellent EMI/RFI protection, ensuring that the signal remains clean and stable even in the presence of external electromagnetic interference.

    The cable is further shielded with a galvanized steel braided OS (outer shield), which provides additional EMI/RFI protection, minimizing noise interference and ensuring signal clarity. The jacket is made of FEP, which provides additional mechanical protection to the conductors.

    The cable is rated for a temperature range of -60℃ to +180℃, which makes it suitable for use in a wide range of applications, including professional audio, recording studios, and broadcast facilities. The cable is also rated as a multi-pair audio cable, which means it is suitable for use in audio applications where multiple signals need to be transmitted.

    Generally speaking, this 2pr*30awg double shielded audio cable is a reliable, high-performance cable that can be used in a variety of applications where signal quality and noise immunity are crucial. Its combination o

    Patrick Dingzun Cable:
    Generally speaking, this 2pr*30awg double shielded audio cable is a reliable, high-performance cable that can be used in a variety of applications where signal quality and noise immunity are crucial. Its combination of high-quality materials, shielding, and temperature ratings make it an excellent choice for use in demanding environments where audio clarity and accuracy are essential.


    ARMORED CABLE
    PAIRSnominal conductor diameternominal insulation thicknessinner thicknessinner diameterarmor steel diameterJacjet thicknessMax. Overall Diameterestimated weight
    pairsmmmmmmmmmmmmmmKg/Km
    2(0)0.90.30.85.70.91.310.1200
    50.90.319.40.91.414.1370
    100.90.31.1131.251.518.6610
    200.90.31.216.81.251.622.7930
    300.90.31.419.91.61.726.71390
    500.90.31.625.41.61.932.61940
    1000.90.31.935.52244.13700
    SHIELDED
    2(0)0.90.30.86.20.91.310.6220
    50.90.319.90.91.414.6380
    100.90.31.113.51.251.519.1630
    200.90.31.217.31.251.623.2955
    300.90.31.420.41.61.727.21415
    500.90.31.625.91.61.933.12000
    1000.90.31.9362244.63750
    NON-ARMORED CABLE
    pairsnominal conductor diametersection areainsulation thicknessjacket thicknessMax. Overall Diameterestimated weight
    pairsmmmm2mmmmmmKg/Km
    NON-SHIELDED
    2(0)0.90.640.31.35.745
    50.90.640.31.49.4115
    100.90.640.31.513205
    200.90.640.31.616.8380
    300.90.640.31.719.9570
    500.90.640.31.925.4920
    1000.90.640.3235.51820
    SHIELDED
    2(0)0.90.640.31.36.250
    50.90.640.31.49.9125
    100.90.640.31.513.5215
    200.90.640.31.617.3390
    300.90.640.31.720.4580
    500.90.640.31.925.9940
    1000.90.640.32361850
