Brand Name : | Dingzun |
Model Number : | 01-16 |
Certification : | UL,CE,ISO9001 |
Price : | Negotiable |
Payment Terms : | L/C, T/T |
Supply Ability : | 3000M/DAY |
Delivery Time : | 15DAYS |
AWG | Section (mm2) | Conductor No./Dia. (mm) | Avg. Insulation Thickness (mm) | Min. Insulation Thickness (mm) | Overall Dia. (mm) | Max. Resistance 20℃(≤Ω/km) |
32 | 0.03 | 7/0.08 | 0.31 | 0.285 | 0.82 | 588.3 |
1/0.20 | 0.31 | 0.285 | 0.86 | 664.8 | ||
30 | 0.05 | 7/0.10 | 0.31 | 0.285 | 0.874 | 361 |
1/0.254 | 0.31 | 0.285 | 0.92 | 381 | ||
28 | 0.08 | 7/0.12 | 0.31 | 0.285 | 0.94 | 227 |
1/0.32 | 0.31 | 0.285 | 0.98 | 239 | ||
26 | 0.13 | 7/0.16 | 0.31 | 0.285 | 1.02 | 143 |
1/0.41 | 0.31 | 0.285 | 1.10 | 150 | ||
24 | 0.22 | 7/0.20 | 0.31 | 0.285 | 1.12 | 89.3 |
1/0.50 | 0.31 | 0.285 | 1.22 | 94.2 | ||
22 | 0.33 | 1/0.65 | 0.31 | 0.285 | 1.27 | 56.4 |
19/0.16 | 0.31 | 0.285 | 1.42 | 59.4 | ||
20 | 0.5 | 1/0.80 | 0.31 | 0.285 | 1.42 | 35.2 |
19/0.18 | 0.31 | 0.285 | 1.57 | 36.7 | ||
18 | 0.8 | 19/0.23 | 0.31 | 0.285 | 1.77 | 23.2 |
17 | 1.0 | 19/0.26 | 0.31 | 0.285 | 1.92 | 18.3 |
16 | 1.3 | 19/0.30 | 0.31 | 0.285 | 2.12 | 14.6 |
Remarks: more AWG available, pls. contact us |
1. Are you a manufacture or trading company?
We are a professional manufacture over 18 years, and our factory
based in Shanghai. Warmly welcome to visit us.
2. Does your company accept OEM production?
Sure, our company policy is Order Oriented Customization, we could
print your brand and produce according to your specification, if
the minimum quantity achieved.
3. What about the lead time for mass production?
Our production capacity is sufficient, normally 10-20 days we can
deliver your order, only if quantity is big, we’ll offer you
specified delivery time.
4. What’s your minimum quantity?
Usually 100m, however cable is heavy product, the freight really
costs, we suggest a reasonable quantity.
5. How can I get a sample to check your quality?
Samples are free for customer; you only need to pay the courier
charge.
6. How does you company control the quality?
Our company has a team of experienced QC, who do in-line and finished goods inspection, we even got certificate of ISO9001. Our products have been certified by UL, CE, SGS, RoHS, CCC etc.
![]() |
